Electrodes, MIG wire and TIG rod — in stock at Paschim Vihar. On code work the third-party approval decides the purchase, so every approval each product holds is listed.
Stick electrodes (SMAW)
| Product | Classification | Coating | Current | Yield / Tensile | What it's for | |
|---|---|---|---|---|---|---|
| ESAB 28 | AWS E6013 · EN ISO 2560-A E 38 0 RC 11 · IS 814 ERR4212X | Rutile, medium heavy | AC, DC± · min AC OCV 50 | 420 / 510 MPa · 28% | General structural steel, all positions · radiographic quality, low spatter, self-detaching slag | PDFQuote |
| ESAB 36H | AWS E7018 · EN ISO 2560-A E 42 3 B 32 H5 · IS 814 EB5426H3JX | Basic, iron powder | AC, DC+ · min AC OCV 70 | 470 / 550 MPa · 28% | Low hydrogen — <5.0 ml/100 g. Restrained structures, crack-sensitive joints. Must be dried before use | PDFQuote |
| PIPEWELD 6010R | AWS E6010 · IS 814 EC4410X | Cellulosic | DC+ only | 440 / 520 MPa · 26% | Deep penetration root runs on pipe. Fast-freezing slag · 2.5 mm 50–80 A, 3.15 mm 80–120 A, 4.0 mm 100–150 A | PDFQuote |
MIG wire and TIG rod (GMAW / GTAW)
| Product | Classification | Shielding gas | Yield / Tensile | Impact | What it's for | |
|---|---|---|---|---|---|---|
| ESAB MW1 | AWS ER70S-6 · EN ISO 14341-A G 3Si1 · IS 6419 S4-C504 | M21, C1 | 450 / 560 MPa (M21) · 430 / 530 (C1) | — | Copper coated Mn-Si solid wire · general construction, automotive, shipbuilding, pressure vessels · designed for high wire feed speed and high current | PDFQuote |
| OK TIGROD S2 | AWS ER70S-2 · EN ISO 636-A W 46 3 W2Ti · IS 6419 S1-I504 | I1 (argon) | 460 / 550 MPa · 28% | 120 J at −30 °C | Copper coated Mn-Si TIG rod · light gauge steel in all positions · root runs for pipe and tube | PDFQuote |
Third-party approvals — the reason these get specified on code work.
| Product | Approvals held |
|---|---|
| ESAB 28 | ABS · BIS · BV · CE EN 13479 · DNV · IBR · IRS · LR · NAKS (2.5–4.0 mm) · PDIL |
| ESAB 36H | ABS 3YH5 · BIS · BV 3Y HH · CE · DNV 3YH15 · IBR · IRS 3Y HH · LR 3Y H15 · PDIL · M N Dastur |
| ESAB MW1 | BIS · CE · DNV III MS/III T · IBR · IRS 2M, 1T · LR 1T, 3S H15 · RDSO Class I |
| OK TIGROD S2 | BIS · CE EN 13479 · IBR · PDIL |
| PIPEWELD 6010R | PDIL |
Approvals are the whole argument on code work. If your customer builds pressure vessels, ships or railway stock, the consumable has to carry the right approval — IBR for boilers, LR / DNV / ABS for marine, RDSO for Indian Railways. That is why a cheaper unapproved electrode is not actually cheaper. Tell us the code you're working to and we'll match the consumable → Bulk and repeat-order rates available.
Our own footage, filmed on the shop floor at Paschim Vihar and on customer sites — not manufacturer marketing. Nothing loads from YouTube until you press play.
More machines at work on our channel: youtube.com/@arcweldingcom
Material, thickness, quantity and delivery location are all we need to begin. We represent seven authorised brands, so the recommendation you receive is the one the job calls for.
